Specifications

Ultimate Strength
HMS Description of Material Plain Faced Phenolic Nitrile Faced Phenolic Non-Abestos G-10 G-7 G-11
Water Absorption in Percent 1.10% 0.45% --- 0.05% 0.10 0.20
Hardness Rockwell M 105 --- --- 110 105 112
Tensile With Grain psi 13,000 13,000 --- 50,000 20,000 43,000
Compression Flatwise psi 39,000 39,000 --- 65,000 50,000 60,000
Flexural Flat W/Grain psi 22,000 22,000 3,000 65,000 30,000 57,700
Dielectric Strength VPM 200 200 400 750-800 350 800
Dielectric Constant 4.5 4.5 --- 5.0 4.5 4.5
Max. Cont. Operating Temp. 225°F/107°C 175°F/79.5°C 700°F/371°C 302°F/150°C 430°F/220°C 350°F/177°C
Nema Grade CE --- None G-10 G-7 G-11





Flange Size ASA/ANSI lb. Class GASKETS
“E”O.D. Inches “F”O.D. Inches “D” RTJASA Ring No.
1 150 4-1/4 2-7/16 R-15
300 4-7/8 2-11/16 R-16
400, 600 4-7/8 2-11/16 R-16
900, 1500 5-7/8 2-15/16 R-16
2500 6-1/4 3-3/16 R-18
1-1/4 150 4-5/8 2-13/16 R-17
300 5-1/4 3-1/16 R-18
400, 600 5-1/4 3-1/16 R-18
900, 1500 6-1/4 3-5/16 R-18
2500 7-1/4 3-15/16 R-21
1-1/2 150 5 3-3/16 R-19
300 6-1/8 3-9/16 R-20
400, 600 3-1/8 3-9/16 R-20
900, 1500 7 3-11/16 R-20
2500 7 4-7/16 R-23
2 150 6 3-15/16 R-22
300 6-1/2 4-3/16 R-23
400, 600 6-1/2 4-3/16 R-23
900, 1500 8-1/2 5-7/16 R-24
2500 9-1/4 5-9/16 R-26
2-1/2 150 7 4-11/16 R-25
300 7-1/2 4-15/16 R-26
400, 600 7-1/2 4-15/16 R-26
900, 1500 9-5/8 6-5/16 R-27
2500 10-1/2 6-7/16 R-28
3 150 7-1/2 2-3/16 R-29
300 8-1/8 5-11/16 R-31
400, 600 8-1/4 5-11/16 R-31
900 9-1/2 6-7/16 R-31
1500 10-1/2 6-11/16 R-35
2500 12 7-9/16 R-32
3-1/2 150 8-1/2 6-3/16 R-33
300 9 6-5/16 R-34
400, 600 9 6-3/16 R-34
4 150 9 6-11/16 R-36
300 10 6-15/16 R-37
400 10 6-15/16 R-37
600 10-3/4 7-7/16 R-37
900 11-1/2 7-15/16 R-37
1500 12-1/4 8-1/16 R-39
2500 14 9-1/16 R-38
5 150 10 7-9/16 R-40
300 11 8-5/16 R-41
400 11 8-3/16 R-41
600 13 9-5/16 R-41
900 13-3/4 9-9/16 R-41
1500 14-3/4 9-13/16 R-44
2500 16-1/2 10-13/16 R-42
6 150 11 8-9/16 R-43
300 10 6-15/16 R-45
400 12-1/2 9-9/16 R-45
600 14 10-5/16 R-45
900 15 11-3/16 R-45
1500 15-1/2 10-15/16 R-46
2500 19 12-5/16 R-47
8 150 13-1/2 10-13/16 R-48
300 15 11-15/16 R-49
400 15 11-13/16 R-49
600 16-1/2 12-7/16 R-49
900 18-1/2 13-15/16 R-49
1500 19 13-11/16 R-50
2500 21-3/4 15-1/16 R-51
10 150 16 13-3/16 R-52
300 17-1/2 14-1/16 R-53
400 17-1/2 13-15/16 R-53
600 20 15-9/16 R-53
900 21-1/2 16-15/16 R-53
1500 23 16-15/16 R-54
2500 26-1/2 18-9/16 R-55
12 150 19 15-15/16 R-56
300 20-1/2 16-17/16 R-57
400 20-1/2 16-5/16 R-57
600 22 17-13/16 R-57
900 24 19-7/16 R-57
1500 26-1/2 20-5/16 R-58
2500 30 21-7/16 R-60
14 150 21 17-9/16 R-59
300 23 18-15/16 R-61
400 23 18-13/16 R-61
600 23-3/4 19-3/16 R-61
900 25-1/4 20-5/16 R-62
1500 29-1/2 22-9/16 R-63
16 150 23-1/2 20-1/16 R-64
300 25-1/2 21-21/16 R-65
400 25-1/2 20-5/16 R-65
600 27 22-1/16 R-65
900 27-3/4 22-7/16 R-66
1500 32-1/2 25-1/16 R-67
18 150 25 27-7/16 R-68
300 28 23-5/16 R-69
400 28 23-3/16 R-69
600 29-1/4 23-15/16 R-69
900 31 24-15/16 R-70
1500 36 27-9/16 R-71
20 150 27-1/2 23-11/16 R-72
300 30-1/2 25-9/16 R-73
400 30-1/2 25-5/16 R-73
600 32 26-11/16 R-73
900 32-3/4 27-5/16 R-74
1500 38-3/4 29-9/16 R-75
24 150 32 28-1/16 R-76
300 36 30-5/16 R-77
400 36 30-1/16 R-77
600 37 30-15/16 R-77
900 41 32-13/16 R-78
1500 46 35-5/16 R-79
